Type 4/12 Wiring Trough 1486 Series from Hammond Manufacturing

Type 4/12 Wiring Trough 1486 Series

The Type 4/12 wiring trough from Hammond Manufacturing is dsigned to enclose and protect multiple wiring junctions from dirt, dust, oil, and water, now available in new sizes. Formed from 14 gauge steel, with smooth, continuously welded seams. Features 12 gauge external mounting feet are welded to the back.

Application

  • Designed to enclose and protect multiple wiring junctions from dirt, dust, oil and water.

Standards

  • UL 870 Type 1, 12, 4
  • CSA Type 1, 12, 4
  • Complies with
    • NEMA Type 12, 4
    • IEC 60529, IP66

Construction

  • Formed 14 gauge steel.
  • Smooth continuously welded seams.
  • Butt hinged cover is secured with easily operated stainless steel screw clamps.
  • Oil resistant gaskets are permanently secured.
  • 12 gauge external mounting feet are welded to the back.

Finish

  • Troughs and covers are finished in ANSI 61 gray powder coating.

Part Details

Click Part No, below, for details (e.g., Product drawings, assembly instructions, ship weight)
